Eight balanced microphone inputs via 3-pin XLR female sockets

Eight unbalanced line inputs via 1/4" TS jacks

Each line input can be internally jumpered to function as a channel insert or direct output

Per-channel tone control cuts up to 12 dB of treble (above 6 kHz) or bass (below 200 Hz)

Adjustable trim and level on each channel

Line-level XLR main output can be switched internally to output mic-level signal

Ninth unbalanced input via mono RCA aux input jack

RCA pre-fader output is independent of the master level control

Connect the RCA pre-fader output to the RCA aux input of a second RM82 (available separately) to enable master level control of both devices from the first RM82

Dedicated power switch and LED power indicator

Rack-mountable enclosure occupies just 1 RU of rack space
